DJI Dock 3 Drone-in-the-Box Bundle – 24/7 Fixed Surveillance

DJI Dock 3: the drone-in-the-box solution for 24/7 surveillance in Belgium

The DJI Dock 3 Bundle with Matrice 4TD is a drone-in-the-box solution designed for 24/7 fixed surveillance. The station launches, operates and recharges the drone automatically, without a pilot on site. From the FlightHub 2 cloud platform, you can control your missions remotely, day or night, in any season.

Drone Parts Center, a Authorized DJI Enterprise Dealer based in Nivelles, offers this complete package with training, maintenance and feasibility study included. We support companies and public bodies in Belgium and the Benelux in the deployment of autonomous aerial surveillance solutions.

Why choose DJI Dock 3?

The DJI Dock 3 is the third generation of DJI automated dock and the first compatible with vehicle mounting. Compared to the Dock 2, it offers better weather resistance (IP56 vs. IP55), a wider temperature range, and faster charging.

• Ultra-fast charging in 27 minutes — from 15% to 95%, the drone is ready for the next mission in less than 30 minutes
• IP56 certified and operating from -30 °C to +50 °C — operational in all Belgian weather conditions, all year round
• Only 55 kg — installation on roof, mast, container or trailer
• Built-in security cameras — internal and external monitoring of the Dock in Full HD
• Battery backup — maintains communications even in the event of a power outage (battery life of more than 4 hours)
• Built-in RTK — centimeter accuracy for reliable feedback on every mission
• 10-second take-off — maximum responsiveness in the event of an alarm

DJI Dock 3 24/7 Monitoring Pack Contents

This turnkey package includes everything needed to deploy an autonomous aerial surveillance solution in Belgium. Each component has been selected to ensure reliable operation from day one.

Training

Component	Detail
DJI Dock 3	IP56 standalone station, 27 min charging, built-in security cameras, battery backup
DJI Matrix 4TD	IP55 thermal drone, 49 min flight, 112× optical zoom, 4 cameras + laser rangefinder
DJI FlightHub 2 Business (12 months)	Cloud-based fleet management and autonomous mission platform
Zen Plus Pack 2 years	Complete drone + dock maintenance by our workshop in Nivelles
FlightHub 2 Level 1	Getting started and best practices (1 day)
FlightHub 2 Level 2 Training: Dock 3	Advanced configuration, automated missions, maintenance (1 day)

DJI Matrice 4TD: the thermal drone of the pack

The DJI Matrice 4TD is specifically designed to work with the Dock 3. It features four cameras and a laser rangefinder, providing exceptional versatility for 24/7 fixed surveillance. Its flight time is up to 49 minutes and its IP55 certification guarantees resistance to dust and splashing water.

• Infrared thermal camera: 640 × 512 pixels, f/1.0, 53 mm equivalent — super-resolution 1280 × 1024
• Wide-angle camera: 1/1.3″ CMOS sensor, 48 MP, f/1.7, 24 mm equivalent
• Medium TV camera: 1/1.3″ CMOS sensor, 48 MP, f/2.8, 70 mm equivalent
• TV camera: 1/1.5″ CMOS sensor, 48 MP, f/2.8, 168 mm equivalent — 112 hybrid zoom×
• Laser rangefinder: range 1800 m at 1 Hz
• Night Scene Mode: Color vision in low-light conditions
• NIR auxiliary lighting for night operations
• Obstacle avoidance: omnidirectional binocular system + 3D infrared sensor

The thermal imaging camera detects heat leaks, temperature anomalies and intrusions even in complete darkness. The 48 MP TV camera captures details — signs, cracks, people — from more than 250 meters away. By tilting the pod up to 80°, the M4TD even inspects the underside of structures such as bridges.

FlightHub 2: The DJI Dock 3 Control Center

DJI FlightHub 2 is the cloud platform that brings the 24/7 surveillance system to life. From a simple web browser, you can manage all your automated assignments, wherever you are.

• Mission planning — set routes, schedules, and triggers (alarm, weather, calendar)
• Remote piloting — take control of the drone from anywhere via web browser
• Live video stream—real-time visual and thermal with annotations
• Intelligent detection — automatic identification of vehicles, people and boats with alerts
• Change detection — comparing images between successive missions to identify any changes
• History and reports — archived flight logs, captures, and thermal analysis
• Multi-site management — multiple Docks managed from a single interface

The Swap Task feature allows two Dock 3 devices to rotate their drones alternately. While one is charging, the other is flying. This rotation provides truly uninterrupted air coverage.

AI detection and custom models

Developers can deploy their own object recognition models on the Matrice 4TD, thanks to the onboard computing power of 10 TOPS. DJI provides the tools for training, validating, and distributing the models. This capability opens up a variety of perspectives: vehicle counting, identification of defects, detection of wild animals.

Use cases in Belgium and Benelux

Perimeter surveillance of sensitive sites

The DJI Dock 3 for 24/7 surveillance automates aerial patrols of industrial sites, power plants, logistics depots and port areas. The drone takes off on program or on alarm triggering, flies over the area and transmits the thermal video stream in real time to the remote operator.

Recurring infrastructure inspection

Power lines, solar panels, pipelines and wind turbines: Dock 3 runs inspection rounds at scheduled intervals. The infrared camera identifies abnormal hot spots. The TV camera detects cracks and structural defects from a long distance. The results are automatically archived in FlightHub 2.

Public Safety and Alarm Response

Law enforcement, emergency services and local authorities benefit from permanent air cover of sensitive areas, ports and borders. The automatic activation of the drone on intrusion detection allows a response in a few seconds, well before the arrival of the ground teams.

Environmental monitoring

Vegetation monitoring, water level measurement, air quality monitoring: detecting changes by comparing images offers a powerful tool for long-term environmental monitoring. Repetitive assignments ensure consistent accuracy without requiring field personnel.

European certification and regulatory compliance

The DJI Dock 3 and the Matrice 4D/4TD drones are C2 and C6 certified by EASA. This dual certification is essential for automated operations in the Specific category within the European Union. DJI provides the documentation needed for regulatory compliance free of charge.

Before any installation in Belgium, our team based in Nivelles carries out a free feasibility study covering 4G coverage, obstacles, flight zones, power supply and EASA and Belgian DGTA compliance. We also support you in the procedures with Skeyes and the STS01 and SORA training.

Why order this pack from Drone Parts Center?

As a DJI Enterprise Authorized Dealer and Dock 3 Certified, Drone Parts Center has the technical and regulatory expertise to deploy your Autonomous Aerial Surveillance solution in Belgium and the Benelux.

• DJI Enterprise Dock 3 certified distributor based in Nivelles
• Free feasibility study before installation
• On-site installation and commissioning included
• Two days of training FlightHub 2 (Level 1 + Level 2 Dock 3)
• Zen Plus 2-year pack : complete drone and station maintenance by our workshop
• Repair service and local technical support
• DJI Care Enterprise Plus available as an option

The price of the DJI Dock 3 package varies depending on the configuration chosen: choice of drone (Matrice 4D or 4TD), connectivity accessories (D-RTK 3, Cellular Dongle 2), warranty options, and installation specifics. Ask for your personalized quote or call Drone Parts Center at +32 67 88 37 37.

---

Protect your investment

Your DJI Matrice 4TD is a working tool. Drone Parts Center, Authorized DJI Enterprise Dealer for the Benelux, offers the official DJI services and safety equipment suited to your platform:

The Matrice 4TD drone in your pack ships with 1 year of DJI Care Enterprise Plus. Remember to extend this protection before it ends: renewal must take place before expiry or within the following 15 days.

• DJI Care Enterprise Plus renewal (DJI Matrice 4TD): extend the coverage included with your drone. Free repair or replacement within the coverage limit, no deductible, round-trip shipping covered by DJI. Renewable up to 3 consecutive years in total.
• DJI Maintenance Standard (DJI Matrice 4TD): detailed 8-point inspection, deep cleaning, full update and calibration, replacement of commonly worn parts (shell, propellers, landing gear, antenna, screws), official DJI maintenance report. The Basic and Premium plans are detailed in the comparison table.
• Dronavia Kronos M4D parachute: EASA-compliant class C5 conversion kit (MoC M2 + MoC 2511) with integrated FTS, enabling STS-01 standard scenario operations, including over populated areas or near uninvolved persons.
• FlightHub 2 Level 1 training: onboarding and best practices for the DJI FlightHub 2 platform, delivered by our trainers.
• DJI FlightHub 2 Business license (12 months): fleet management, mission planning and remote supervision of your dock and drones.
