DJI Matrix 4TD Fire & Rescue Pack

DJI Matrice 4TD Fire & Rescue Pack: The Thermal Drone Designed to Save Lives

The DJI Matrice 4TD firefighter drone is transforming rescue operations in Belgium. This complete package equips rescue zones, firefighters and civil protection with an aerial platform capable of detecting victims under the rubble, monitoring the spread of a fire and coordinating ground teams in real time. According to a study conducted by EENA and DJI, the use of a drone reduces the time it takes to locate a missing person by 65% compared to a purely pedestrian search.

Drone Parts Center, the Authorized DJI Enterprise Dealer in Nivelles, assembled this pack based on field feedback from more than 20 police zones, 4 rescue zones and the Belgian civil protection. Each component responds to an operational need identified during real intervention missions.

High-sensitivity thermal camera: detecting the invisible during an intervention

The heart of the DJI Matrice 4TD firefighter drone is its 640×512 pixel thermal sensor. Its sensitivity of less than 50 mK makes it possible to distinguish a human body through thick smoke, under rubble or in a dense wooded area. In super-resolution mode, the image reaches 1280×1024 pixels, offering an unparalleled level of detail.

This infrared sensor is accompanied by three complementary optical cameras. The 48 MP wide-angle camera (24 mm, f/1.7) provides an overview of the disaster. The 48 MP (70 mm) medium-tele camera allows structural damage to be assessed at medium distances. Finally, the 48 MP (168 mm) telephoto camera with 112x hybrid zoom identifies critical details, such as the condition of a floor or roof, from a safe distance.

Concrete use case: thermal reconnaissance of a burning building

Before engaging ground crews, the Operations Commander deploys the Matrice 4TD to obtain a thermal map of the building. In less than 3 minutes, the drone identifies hotspots, areas of potential spread and possible trapped victims. This information, transmitted live via DJI FlightHub 2, allows for informed tactical decisions to be made before any engagement.

Tactical equipment: AL1 projector and AS1 loudspeaker

Night-time interventions represent a major challenge for the emergency services. The DJI AL1 Spotlight projector, integrated into the pack, delivers 2000 lumens to illuminate an area of operation from the air. It also serves as an aerial beacon to guide ground crews to victims located by the thermal camera.

The DJI AS1 Speaker completes the device with a power of 120 dB. It allows direct communication with victims, evacuation instructions or guidance to teams in noisy environments. These two accessories turn the DJI Matrice 4TD firefighter drone into a true air command tool.

Package Contents: Everything you need to get up and running

Battery

Component	Detail
DJI Matrix 4TD	Complete drone + 1 battery + RC Plus 2 remote control
4× DJI Matrix 4D Series	5 batteries in total for extended operations
2× DJI Cellular Dongle 2	4G LTE connectivity for video transmission to PC Ops
DJI AL1 Spotlight	2000 lumen floodlight for night operations
DJI AS1 Speaker	120 dB loudspeaker for victim communication
RC Plus 2 Strap	Strap and support for operational comfort of the pilot

This pack includes 5 batteries in total, guaranteeing a cumulative battery life of more than 4 hours in the field. The two DJI Cellular Dongle 2 4G modems provide stable video transmission to the Operations PC, even in areas with limited network coverage.

Robustness and autonomy: operational in all conditions

The DJI Matrice 4TD firefighter drone is IP55 certified. It is resistant to driving rain, dense smoke and dust splashes. Its operating range is from -30°C to +50°C. In Belgium, this robustness makes it possible to intervene all year round, regardless of the weather conditions.

With 49 minutes of battery life and a 15% to 95% charge in just 27 minutes, the Matrice 4TD covers large-scale operations without interruption. It takes off in 10 seconds, a crucial asset in emergency operations where every moment counts.

Obstacle Avoidance System

The omnidirectional detection system locates 12 mm electrical cables at a flight speed of 15 m/s. This capability significantly reduces the risk of collision during low-level flights over disaster areas, where infrastructure can be damaged and unpredictable.

Missions covered by this rescue drone pack

• Search for missing persons in natural areas: forests, rivers, uneven terrain
• Thermal reconnaissance of burning buildings before the teams are engaged
• Fire spread monitoring and residual hot spot detection
• Post-disaster damage assessment: flood, storm, collapse
• Real-time aerial coordination of ground crews
• Support for GRIMP operations and interventions at height

FlightHub 2 integration: the Operations PC connected to the drone

Thanks to the two built-in 4G modems, the Matrice 4TD retransmits the thermal video stream in real time to DJI FlightHub 2. The Operations Commander follows the mission from his tablet, annotates the map and coordinates the ground teams. This software integration is a decisive asset for crisis management, as it centralizes tactical information in a single point.

FlightHub 2 also integrates intelligent AI object detection: vehicles, boats, thermal anomalies. These automated features speed up the search for victims and improve the responsiveness of response teams.

Regulatory framework: Belgian rescue zones and EASA exemptions

Belgian rescue zones benefit from legal exemptions under EU Regulation 2019/947, Article 2.3.a, for civil protection and rescue missions. These exemptions greatly simplify the operational deployment of the DJI Matrice 4TD firefighter drone during emergency response.

Our team offers a one-day tactical rescue pilot training , adapted to the specific needs of firefighters and civil protection teams.

Additional services for emergency areas

• DJI Care Enterprise Plus: Express drone replacement in the event of a crash, to minimize equipment downtime
• 2-year Zen Plus pack: complete maintenance program in our workshop in Nivelles, including calibration and firmware updates
• Tactical rescue flight training: 1 day in real conditions for your operational pilots

Our maintenance packages are designed to ensure that your fleet is always available. In the event of a breakdown or crash, our drone repair service ensures fast care.

Why choose Drone Parts Center to equip your rescue zone?

Drone Parts Center is the Authorized DJI Enterprise Dealer of reference in the Benelux for public safety. Our packs have been validated in the field by more than 20 police zones, 4 rescue zones and the Belgian civil protection. We offer intra-community invoicing (excluding VAT) and accept purchase orders from public administrations. Delivery is made within 24 hours throughout the Benelux.

Each rescue zone has specific needs. Contact us for a personalized quote on +32 67 88 37 37. Our technical team advises you on the optimal configuration according to your missions and your budget.
