The power of multiple sensors for operational excellence: dual nacelle, maximum flexibility and optimized performance

Transform your missions with the Matrice 400 Dual Gimbal Connector

The Matrice 400 Dual Gimbal Connector represents a revolution in multi-sensor capabilities for professional drones. Specifically designed for the DJI Matrice 400, this innovative connector allows for the simultaneous mounting of two gimbals with an optimized capacity of 950g each, opening up a world of possibilities for applications requiring complementary data or multiple perspectives. This revolutionary solution transforms the Matrice 400 into a true multi-sensor acquisition platform capable of simultaneously collecting different types of data.

This technological innovation meets the growing needs of professionals who require sophisticated sensor configurations for their missions. Whether combining visible and thermal imaging, integrating measurement and monitoring sensors , or deploying complementary inspection systems, the Dual Gimbal Connector provides the flexibility and capability to maximize mission efficiency and the quality of the data collected.

Multi-sensor architecture and design

At the heart of the Matrice 400 Dual Gimbal Connector is a sophisticated mounting architecture that optimizes the use of available space while maintaining the drone’s balance and flight performance. The connector incorporates a bottom mounting system that positions the two gimbals optimally to avoid mutual interference while maximizing the available viewing angles.

This intelligent design allows operators to configure the pods to their specific mission requirements. Adjustable mounting positions make it easy to optimize viewing angles and minimize shadow areas, while the built-in balancing system ensures that the addition of two pods does not negatively affect the flight performance of the Matrice 400.

Payload optimization and performance

The capacity of 950g per pod has been carefully calculated to optimize the balance between load capacity and flight performance. This intelligent limitation ensures that the drone maintains its exceptional flight characteristics while allowing the integration of high-quality professional sensors . The Distributed Load Management system automatically optimizes weight distribution to maintain optimal balance.

This balanced approach allows operators to deploy complementary sensor configurations simultaneously without compromising safety or performance. The system automatically recognizes connected payloads and adapts flight parameters accordingly, optimizing range and stability depending on the configuration used.

Technical specifications and capabilities

Mounting and Charging Characteristics

Capacity

position

Type

interface

Characteristic	Specification
Model	Matrice 400 Dual Gimbal Connector
Compatibility	DJI Matrice 400 exclusively
Number of platforms	2 simultaneous platforms
Capacity per basket	950g maximum each
Total	1.9 kg (2 × 950g)
Mounting	Lower under the drone
Fastening	Secure locking system
Electrical	Dual integrated into Matrice 400 systems

Performance and impact on flight

The flight performance impact of the Dual Gimbal Connector has been painstakingly optimized to maintain the exceptional capabilities of the Matrice 400. The balanced distribution of payloads over two mounting points improves stability compared to an equivalent single load, while maintaining the essential flight characteristics of the drone.

The Matrice 400’s intelligent flight management system automatically adapts to the presence of dual payloads, adjusting control parameters, speed limits, and flight profiles to maintain safety and stability. This automatic adaptation ensures optimal performance regardless of the sensor configuration used.

Business applications and use cases

Multi-spectral industrial inspection

For industrial inspection applications, the Dual Gimbal Connector allows high-resolution visible imaging and infrared thermography to be combined simultaneously, revolutionizing inspection efficiency. This multi-spectral approach allows for the simultaneous detection of visual defects and thermal anomalies, providing a complete analysis in a single mission.

Sensor synchronization allows visual and thermal data to be precisely correlated, making it easier to identify complex problems that would traditionally require multiple passes. This improved efficiency reduces inspection times, operational costs, and improves the quality of diagnostics provided to customers.

Precision mapping and topography

In the field of mapping and surveying, the Dual Gimbal Connector makes it possible to combine high-resolution photogrammetry with specialized measurement sensors such as LiDARs or multispectral sensors. This multi-sensor approach significantly improves the accuracy and richness of the data collected, allowing for the creation of detailed 3D models with complementary spectral information.

Simultaneous data collection eliminates time synchronization problems and ensures perfect consistency between different types of measurements. This approach is particularly valuable for large-scale projects where data accuracy and consistency are critical to the quality of final deliverables.

Monitoring and advanced security

For surveillance applications, the Dual Gimbal Connector allows the creation of omnidirectional surveillance systems that combine high-resolution cameras pointing in different directions or visible and infrared sensors for 24-hour surveillance. This multi-sensor configuration significantly improves surveillance efficiency by eliminating blind spots and providing additional information.

Public safety operations particularly benefit from this capability by being able to simultaneously deploy day and night vision systems, motion detection sensors, and communications equipment. This configuration transforms the Matrice 400 into a true aerial surveillance center capable of efficiently covering large areas with exceptional data quality.

Setup and installation

Installation and safety procedures

The installation of the Dual Gimbal Connector follows strict procedures designed to ensure optimal safety and performance. The installation process requires careful attention to load balancing and synchronizing the systems to ensure that the two nacelles operate harmoniously without mutual interference.

Safety checks include distributed load tests, dynamic balancing checks, and integrity checks for dual electrical connections. These procedures, while detailed, are essential to ensure flight safety and prevent failures that could damage the drone or compromise the mission.

Optimization of multi-sensor configurations

Optimizing configurations is a critical aspect of using the Dual Gimbal Connector. Relative nacelle positioning, sensor orientation, and synchronization of acquisitions must be carefully planned to maximize data collection efficiency and minimize sensor interference.

Built-in planning tools allow you to simulate different configurations and optimize parameters according to mission objectives. These tools provide real-time recommendations for adjusting editing positions and optimizing capture sequences, ensuring that each configuration reaches its maximum potential.

Sensor management and synchronization

Integrated control systems

Managing two pods simultaneously requires sophisticated control systems that coordinate movements, synchronize acquisitions, and optimize overall performance. The Dual Gimbal Connector incorporates coordination intelligence that ensures that the two gimbals operate harmoniously without control conflicts or mechanical interference.

This intelligent coordination allows operators to control both platforms simultaneously through a unified interface, greatly simplifying complex operations. The system can also operate in automated mode where the pods follow pre-programmed sequences optimized for specific mission objectives.

Data synchronization and workflow

The synchronization of the data collected by the two gimbals is a major advantage of the Dual Gimbal Connector. The system ensures precise time synchronization between the different sensors, facilitating data correlation and analysis in the post-processing phases. This synchronization is critical for applications that require multi-sensor data fusion.

Built-in processing workflows make it easy to organize and analyze the data collected simultaneously by the two pods. These tools automate spatial and temporal correlation tasks, significantly reducing post-processing times and improving the quality of final analyses.

Operational and economic benefits

Mission efficiency and cost reduction

The Matrice 400 Dual Gimbal Connector generates substantial efficiencies by enabling multiple types of acquisitions to be consolidated into a single engagement. This consolidation drastically reduces flight times, travel costs and personnel requirements, significantly improving the profitability of business operations.

Reducing the number of flights required to collect all the required data also reduces equipment wear, operational risks and the environmental impact of missions. This optimization is particularly valuable for large-scale projects where economies of scale can be substantial.

Data quality and added value

The simultaneous collection of complementary data greatly improves the quality and richness of the information provided to customers. This multi-sensor approach makes it possible to offer more complete analyses and more accurate diagnoses, justifying premium rates and improving customer satisfaction.

This qualitative differentiation is a decisive competitive advantage in professional markets where added value takes precedence over cost. The ability to provide synchronized multi-spectral data also opens up new markets and makes it possible to respond to more complex and better-paid calls for tenders.

Maintenance and technical support

Maintenance of dual systems

Maintenance of the Dual Gimbal Connector requires special attention to synchronization systems and dual load balancing. Regular inspections include checking the alignment of the nacelles, checking the coordination systems, and inspecting multiple electrical connections. These specialized procedures ensure that the optimal performance of the dual system is maintained.

Advanced diagnostic tools allow each pod to be monitored individually while analyzing their overall coordination. This differential diagnostic approach facilitates the early identification of problems and enables targeted maintenance that minimizes downtime.

Specialized multi-sensor technical support

DJI Technical Support for the Dual Gimbal Connector includes specialized expertise in multi-sensor configurations and synchronization of complex systems. Technicians can provide in-depth assistance with optimizing configurations, troubleshooting coordination issues, and adapting to specialized workflows.

Advanced training programs cover the technical, operational, and analytical aspects of using the Dual Gimbal Connector. These trainings ensure that operators have a thorough understanding of the configuration, synchronization and analysis procedures necessary to fully exploit the capabilities of the dual system.

Frequently Asked Questions

Why is the capacity limited to 950g per carrycot?

This limitation optimizes the balance between load capacity and flight performance. It ensures that the drone maintains its exceptional flight characteristics while allowing the integration of high-quality professional sensors. This balanced approach maximizes overall operational efficiency.

Can the two pods work independently?

Yes, each pod can be controlled independently or in coordination according to mission needs. The system offers complete flexibility: unified control, independent control or pre-programmed automated sequences.

How can I avoid interference between sensors?

The system incorporates coordination algorithms that prevent mechanical and electronic interference. Planning tools also help optimize configurations to minimize interference depending on the types of sensors used.

Does the Dual Gimbal Connector affect battery life?

The addition of payloads reduces the range in proportion to the total weight. However, the balanced two-point distribution improves efficiency compared to an equivalent single load. The system automatically adjusts range estimates.

Can I combine with the Third Gimbal Connector?

Yes, the Matrice 400 can support the Dual Gimbal Connector and the Third Gimbal Connector simultaneously, allowing up to three simultaneous pods within the maximum total payload. This configuration offers exceptional possibilities for complex applications.

What types of sensors are recommended?

The most efficient configurations combine complementary sensors: visible + thermal, photogrammetry + LiDAR, or multi-directional monitoring. The choice depends on the specific mission objectives and data requirements.

Configuration and accessories

The Matrice 400 Dual Gimbal Connector includes:

• Main connector with dual mounting systems
• Secure locking systems for each carrycot
• Dual wiring and electrical interfaces
• Technical documentation and configuration procedures
• Synchronization and coordination software

Why choose the Matrice 400 Dual Gimbal Connector

The Matrice 400 Dual Gimbal Connector represents the ultimate evolution of multi-sensor capabilities for professional drones. This revolutionary solution transforms single sensor limitations into opportunities for innovation with its optimized dual configuration, intelligent synchronization , and native integration.

Strategic investment justified by:

• Dual configuration for simultaneous multiple sensors
• Optimized capacity 950g per pod for balanced performance
• Smart synchronization and automatic coordination
• Operational efficiency with mission consolidation
• DJI Enterprise Support and Specialized Multi-Sensor Expertise

The Matrice 400 Dual Gimbal Connector isn’t just a mounting accessory, it’s a capability multiplier that unlocks the full potential of your DJI Matrice 400 and opens up new horizons for your most sophisticated professional applications.
