DJI FlightHub 2 On-premises

DJI FlightHub 2 On-premises drone management platform for maximum safety

The DJI FlightHub 2 On-premises drone management platform is a complete solution for managing your drone operations autonomously. This system enables you to plan missions, supervise your fleet and manage your data in your own infrastructure.

Unlike the standard cloud version, this self-hosted edition gives organizations the option of running all functionalities in their own data centers or internal servers.

This solution is perfectly suited to the needs of companies requiring data sovereignty and enhanced security to comply with strict protocols.

Recommended technical data

For optimum operation of your drone management platform, we recommend the following configuration:

• CPU: 8 cores
• Memory: 32 GB
• Disk space: 1000 GB
• Network: Minimum speed of 100 Mbps for each connected Dock
• Operating system: Linux/Ubuntu

Private deployment for enhanced data security

Protecting your sensitive information is at the heart of the design of DJI FlightHub 2 On-premises. This solution gives you total peace of mind when it comes to your data.

With private deployment, you can install the platform in a completely isolated intranet environment. This configuration adds an extra layer of security.

The system supports Docker-based deployment, which can be implemented on physical machines within a local network or on private cloud servers.

For added security, you can use third-party accounts compatible with the standard Auth2 protocol. This feature enhances user access management.

Custom development and integration

The platform offers OpenAPI compatibility, modular front ends and an MQTT bridge for versatile system integration. These features enable easy adaptation.

The system adapts easily to your company’s existing workflows, offering industry-ready performance with a focus on operational safety.

You retain all the essential features of DJI FlightHub 2, including live broadcasting, mission planning and recording playback.

Automated deployment with DJI Dock

Combined with DJI Dock stations, the DJI FlightHub 2 On-premises drone management platform enables fully automated, remote workflows. This combination transforms your operations.

You can perform comprehensive tasks such as route planning, flight scheduling and mission execution from a central control point.

The system allows on-demand deployment: set up recurring missions or launch one-off operations from anywhere, while monitoring the live video stream.

Receive alerts in situations that could affect Dock station flights, and check their status remotely for permanent control of your fleet.

Enhanced flight safety

Configure customized geographical and task zones to ensure that the drone follows a precise flight path. This function ensures complete territorial control.

The system ensures that the aircraft remains within a designated area and does not enter restricted spaces, reinforcing the operational safety of your missions.

Virtual cockpit for immersive control

The drone management platform simplifies remote operations with precise control using just a mouse and keyboard. This intuitive interface makes piloting easy.

Features like Mouselook and glide zoom streamline your camera adjustments and flight direction for intuitive, efficient piloting.

FlyTo automation lets you define waypoints at the click of a button. The system automatically calculates a safe and efficient route for your missions.

Intelligent object tracking

Use advanced AI to detect and track vehicles, ships and other objects of interest. This technology greatly enhances your surveillance capabilities.

Automatic alerts and continuous monitoring enable smooth real-time monitoring and better concentration on the core mission.

The Point of Interest (POI) function lets you mark any location on the map. The drone automatically adjusts its orientation for optimum inspection.

Comprehensive supervision for improved coordination

Terrain-sensitive 2.5D mapping enhances your mission planning with hybrid satellite imagery and elevation data. This information provides essential topographical context.

Capture a complete aerial panorama and synchronize it with your operation in a single click. Each panoramic capture is geotagged for improved spatial awareness.

Create high-resolution RGB or thermal orthomosaic maps up to 1.5 km² in a single flight. These visualizations integrate automatically into your interface.

Multi-drone scattering and data analysis

Monitor multiple perspectives simultaneously with support for concurrent video streams. Customizable layouts ensure that every visual detail is captured.

Customize project roles, share live feeds with colleagues and make annotations in real time for optimal collaboration in the field.

After downloading the results, analyze and annotate the data using the platform’s built-in comparison and annotation functions.

Route planning and task management

The DJI FlightHub 2 On-premises drone management platform offers editable waypoint routes using model data. This feature enables full immersive previewing.

Set up intelligent recognition tasks for accurate point-by-point subject detection and documentation, optimizing data collection.

Zone routes are designed for mapping missions. They allow you to avoid restricted areas thanks to advanced configuration.

Specialized routes for different environments

Linear routes are suitable for extended linear environments such as rivers, roads and pipelines. This function divides mapping areas into manageable flight segments.

Intelligent 3D capture uses a preliminary model to create detailed capture paths that follow the contours of the object under study, simplifying modeling.

Sloping routes exploit 3D models to generate routes suitable for capturing data on inclined structures such as bridges or steep terrain.

Geometric routes are ideal for precision mapping of free-standing structures such as buildings. The model’s integrated visualization provides enhanced information on road safety.
